Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity

Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity

    • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity
    • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity
    • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity
    • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity
    • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity
  • Single Stage Fruit Pulping Machine Fruit Processing Equipment 2TPH - 15TPH Capacity

    Product Details:

    Place of Origin: China
    Brand Name: Shanghai Beyond
    Certification: ISO9001/CE/SGS
    Model Number: BY-SSP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PCS
    Price: negotiable
    Packaging Details: Export standard package
    Delivery Time: 50 working days upon receipt of payment and confirmed the drawings
    Supply Ability: 10pieces/month
    Contact Now
    Detailed Product Description
    Raw Material: Fruit Main Material For Machines: SUS304 Or SUS316
    Capacity: 2TPH-15TPH Warranty: One Year
    Advantage: Easy To Clean And Assembly And Disassembly

    Single Stage Pulping Machine Fruit Processing Equipment Pulp and Residue Separate Automatically



    Usage: this machine can be used to pulp on the following fruits;

    • stone fruits after the stone has been removed, such as mango, peach, apricot, date;
    • Also used for the baccas (Chinese goosebeery and strawberry);
    • kernel fruits after been cooked and softened(such as apple,pear,pumpkin)

    Characteristics:

    • fruit pulp and the dreg separate automatically;
    • can be mounted in a processing line, and also can perform the production by its own.
    • All the material where contact with the product is made of high quality stainless steel which meet the standard of food requirements.
    • Easy to clean and disassemble and assemble.

    Technical parameter

    Model Description

    External dimension(mm)

    (L*W*H)



    Suggested capacity Suggested power

    capacity and power varies as to

    different fruits

    DDJ-2



    All made of sus304 stainless steel ,rotating at 960-1350 rpm



    1170*600*1250 ≤2(T/H) 5.5
    DDJ-5 1760*800*1500 3~5(T/H) 15
    DDJ-10 1950*1050*1880 6~10(T/H) 22
    DDJ-15 2150*1050*1880 11~15(T/H) 30
