SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    • SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control
    • SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control
    • SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control
  • SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    Product Details:

    Place of Origin: Shanghai China
    Brand Name: Shanghai Beyond
    Certification: ISO9001:2008/SGS/CE
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: USD400000-USD500000 per set
    Packaging Details: Standard export package
    Delivery Time: 90-120 days upon receipt of payment and drawing confirmation
    Payment Terms: T/T, L/C
    Supply Ability: 10 set per month
    Contact Now
    Detailed Product Description
    Material: SUS304/SUS316L Stainless Steel Control: Automatic Control
    Energy Consumption: Low Energy Consumption Efficiency: Hgih Efficiency
    Warranty: 1 Year After-sales Service: Engineer Available To Serive Machinery Overseas

    Description of UHT milk production line long life milk processing plant



    This UHT milk production line long life milk processing plant can produce several types of pasteurized milk products, i.e. whole milk, skimmed milk, standardized milk of various fat contents, meanwhile with options to produce yogurt, cheese, cream and butter etc.



    This UHT milk production line long life milk processing plant uses fresh milk or milk powder as raw material, which normally be stored at low temperature about 4 or 5 degree, this method can maintain the nutrition at maximum.



    End package form of this UHT milk production line long life milk processing plant can be plastic bag, plastic cup, plastic bottle, glass bottle, roof top box etc. Our enginner will design it according to your requirements since technical parameters and skills are different for different package form.



    Drawing of UHT milk production line long life milk processing plant



    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    No. Flow No. Name Size Main technology parameter Unit QTY
    1 A Milling unit(Rice processing line, sharing with oatsprocessing)
    2 A-0 Rice washing machine Q=500Kg/h SUS304 set 1
    3 A-1 Cooking kettle 1000L SUS304 stainless steel, three layer miller jacket, half open type, central frame blender, bottom flange outlet, with built-in scale set 2
    4   temperature control system   UK Sprirax sarco steam reduce system,Burket angle valve, JUMO temperature sensor set 1
    5 A-2 Screw pump Q=2T/h made of sus304 stainless steel, pump lift is 60m set 2
    6 A-3 Operating platform   made of sus304 stainless steel, size:4000*1000*1500mm set 1
    7 A-4 Colloid mill Q=2T/h made of sus304 stainless steel,JMS-180 set 2
    8 A-5 Buffer tank 300L made of sus304 stainless steel, set 1
    9 A-6 Rotor pump Q=2T/h made of sus304 stainless steel, pump lift is 60m set 1
    10 A-7 Temporary storage tank 2000L SUS304,double layers, PU insulation, vertical agitator, airtight manhole,ladder,digital readout thermometer,CIP cleaning ball, glass tube level indicator set 2
    11 A-8 Rotor pump Q=3~5T/h made of sus304 stainless steel, pump lift is 60m set 1
    12   Subtotal A:
    13 B Melting unit
    14 B-1 High speed
    emulsification tank
    V=600L made of sus316L stainless steel, with insulation, with high speed shearing mixer mounted from bottom, speed is 1400rpm, with digital show thermometer, with level scale inside wall set 1
    15 B-2 Centrifugal pump Q=5T/h made of sus316L stainless steel, pump head is 24m, ABB motor set 1
    16 B-3 Twin pipe filter Q=5T/h SUS316, mesh size 100M set 1
    17 B-4 Platform   SUS304,size:1200*1000*1200mm pcs 1
    18   Subtotal B:
    19 C Blending unit
    20 C-1 blending tank V=2000L made of sus316L stainless steel, with insulation, vertical agitator 43rpm, with attachments sucha as manhole, ladder and digital show thermometer, CIP cleaning head, product enter from side, glass tube level indicator set 3
    21 C-2 centrifugal pump Q=3T/h made of sus316L stainless steel, pump head is 24m, ABB motor set 2
    22 C-4 high pressure homogenizer 1.5T/h SUS316L, 25Mpa, (starting box included) pcs 1
    23 C-5 blending platform   SUS304,6000*800*1500mm pcs 1
    24   Subtotal C:
    25 D Heating unit
    26 D-1 Temporary
    storage tank
    V=1000L made of sus316L stainless steel, with insulation, vertical agitator 43rpm, with attachments sucha as manhole, ladder and digital show thermometer, CIP cleaning head, product enter from side, glass tube level indicator set 1
    27 D-2 Centrifugal pump Q=5T/h made of sus316L stainless steel, pump head is 36m, ABB motor set 1
    28 D-3 Plate heat exchanger 1.5T/H SUS316L, two section type,△T1=20℃, hot water heating, Spirax sarco steam regulating system, stainless steel steam and water mixer, Jumo temperature sensor, include hot water tank and hot water pump, second section is for tower water cooling, can cool product from 80 to 60℃ pcs 1
    29   Subtotal D
    30 E Sterilizing and Filling unit
    31 E-1 Tubular pasteurizer 1.5T/H SUS316L stainless steel, aseptic tye, tubular type, sterilizing parameters:137℃,5S,output temperature 30℃,PLC automatic control Set 1
    32 E-2 Full-automatic
    vacuum degasser
    1.5T/H Full-automatic control, SUS316L stainless steel, differential pressure transducer imported from Germany Labom, working vacuum degree -0.64~-0.85Kpa, flow control is frequency converted type, working together with pasteurizer, with condensing device PCS 1
    33 E-3 High pressure homogenizer 1.5T/H SUS316L, 25MPa, including starting cabinet, frequency conversion control PCS 1
    34 E-4 Brick aseptic filling machine   250ml/B, 6000B/H PCS 1
    35   Subtotal E
    36 F Hot water unit
    37 F-1 Hot water tank V=3000L made of sus304 stainless steel, insulated with PU,with airtight manhole, cone top and bottom cover, ladder, glass tube level indicator set 1
    38 F-2 Hot water pump Q=5T/h made of sus304 stainless steel, pump head is 24m, ABB motor set 1
    39 F-3 Plate heater Q=5T/h plate heat exchanger is made of sus304 stainless steel, one cooling section, with plastic seal set 1
    40 F-4 Temperature control system   UK Sprirax sarco steam reduce system set 1
    41   Subtotal F:
    42 G CIP Unit
    43 G Semi-automatic CIP system 3×2T SUS304 stainless steel, double cleaning way, concentrated acid/alkali tank adding system based on US technology, temperature automatic control, 300L×2 acid/alkali concentrate tanks set 1
    44 R CIP return pump 20T/H SUS316L stainless steel, pump lift is 24 meters, mechanical seal set 3



    Packing and shipping



    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control



    Our service and supplier



    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control

    SUS304 Pure Milk Production Line / 2000L/H Milk Processing Plant With PLC Control



    Questions and answers



    Q1: Are you factory? Can we visit your company before place the order?

    A1: Yes, our factory is in Shanghai, China. Welcome to visit us!



    Q2: May I get your product catalog?

    A2: Sure, please feel free to contact me, I will send you our e-catalog.



    Q3: Can you provide me whole production line?

    A3: Of course we can, we are engaged in producing the liquid projects used in dairy, fruit juice, beverage, tea and so on products. We can provide you turnkey project.



    Wish to have further cooperation with you in the future.
