UHT Almond Milk Processing Machine PET Bottle Package
|Place of Origin||CHINA|
|Minimum Order Quantity||1SET|
|Packaging Details||export standard packing, worthy for long distance sea shipping|
|Delivery Time||80-100days upon the recipt of downpayment and confirmation of drawings|
|Payment Terms||T/T, L/C, west union|
|Supply Ability||20 sets per month|
|Material||SUS 304/SUS316||Manufacturer History||More Than 10years|
|Package||PET Bottle, Aluminium Cans, Tin Cans, Standup Pouch Etc||Shelf Life||6-12months|
|Processing Line Type||Complete Turn-key Project||Capacity||1000-100000LPH|
almond milk processing machine,
UHT almond milk processing machine,
almond milk uht sterilization machine
Complete UHT whole milk processing and packaging machine / almond milk processing plant / coconut milk processing plant
|Brand Name:||Shanghai Beyond|
Fresh cow milk, buffalo milk, goat milk, camel milk
or milk powder, or both mixed
|End product||Pure milk, UHT milk, long shelf life milk|
35-40days, 3months, 6months, 12months
(keep at room temperature )
|Final product fat (%)||
Semi-skimmed or double toned milk (1.5%);
Full cream(3% or 6%); Toned milk(3%)
|Main material for machines||SUS304 or SUS316|
|Package for end product||pouch / pillow/brick shape carton|
|Place of Origin:||China|
|Manufacturer history||More than 10years|
Aseptic brick filling machine
Main technical features:
-Full automatic control system: the machine can automatically complete film feeding, forming and sealing, and can control every step of the whole system.
-Lower utility consumption: lower consumption of electricity, compressed air and water, which can reduce customers' costs.
-Advanced pneumatic control system: the pneumatic control system improves the wear problem of the machine and reduces the maintenance work and cost of customers.
-The high-performance air filter ensures the cleanness of the air in the filling room during the production process and greatly improves the sterility of the product.
Plastic bottle filling and sealing machine
Main technical features:
-Use the electrical control system approved by CE standard and the electrical box with waterproof groove.
-Use European or American pneumatic components
-Siemens PLC in Germany, pro face touch screen in Japan, Rexroth servo motor in Germany, Schneider contactor in France, etc. (transformer and reducer of domestic well-known brands) are adopted
-Using precision stepper
-Use engineering plastic formwork
-Thickened double chain made of stainless steel is used to prolong the service life of the chain
-The body adopts stainless steel square tube
-The filling system is fixed by German membrane valve
-Use ceramic pump and ceramic traction valve
-Floating sealing technology is adopted to ensure sealing quality
-Fixed to the sealing hopper, the machine can be connected to the CIP equipment
-Low voltage protection technology is adopted to prevent the machine from starting under low voltage and improve the reliability and stability of the machine
-Use the mechanical blocking safety protection device to ensure the normal operation of the machine
-Easy to clean and maintain
Features and advantages:
1. Processing capacity can be ranged from 2T/Day to 1000T/Day.
2. High standard design, manufacture and project installation requirements, which guarantee the first-class finish products in the dairy processing line.
3. PLC control the whole production line, saving labor force and facilitate production management.
4. Full-auto CIP cleaning, to ensure whole production line equipments meet food sanitary safety requirements.
5. Whole line with features as high level automatic, low labour intensity, easy operation, safe function and low operation cost.
6. Whole line adopt sanitary design, can be cleaned thoroughly, with high level sanitation.
Machine list and Technical data for 8000LPH UHT milk plant :
|Flow No.||Name||Model||Main technical parameters||QTY
|A||Milk reception unit|
|A-1||Milk pump||15T/H||SUS304 stainless steel, pump lift is 24 meters, mechanical seal||2|
|A-2||Twin piping filter||15T/H||Material-touch is SUS304 stainless steel, two pipe, stainless steel filter element 100 mesh||2|
|A-3||Deaerator vessel||15T/H||SUS 304 stainless steel, tangential feeding,bottom discharge||2|
|A-4||Milk pump||15T/H||SUS304 stainless steel, pump lift is 24 meters, mechanical seal||2|
|A-5||Electromagnetic flowmeter||15T/H||SUS 304, 4-20mA Signal output, pulse counting||2|
|A-6||Buffer tank||5000L||SUS304 stainless steel, PU insulation,conical head, sealed manhole, breathing valve,CIP cleaning ball, digital show thermometer, plate anti vortex, adjustable legs||2|
|A-7||Milk pump||15T/H||SUS304 stainless steel, pump lift is 24 meters, mechanical seal||2|
|A-8||Milk clarifier||10000L/H||Disk separator, automatic control, two-phase, started with frequency conversion, self-discharging||2|
|A-9||Plate cooler||15T/H||SUS304 stainless steel, one section, ΔT=16°C, outlet milk temperature is 4°C||2|
|Flowmeter||15T/H||SUS 304, pointer type||2|
|B||Pre-pasteurization & storage unit|
|B-1||Milk storage tank||20000L||SUS304, 60mmPU insulation, skirt base, and inclined bottom discharging, Miller jacket, closed side manhole ladder, guardrail, digital thermometer,sampling valve, Germany JUMO temperature sensor, rambeau static pressure sensor, CIP cleaning ball, breathing valve, lateral mixing 960rpm||4|
|B-2||Milk pump||20T/H||SUS304 stainless steel, pump lift is 24 meters, mechanical seal||1|
|B-3||Milk pump||15T/H||SUS304 stainless steel, pump lift is 24 meters, mechanical seal||1|
|B-4||Plate pasteurizer||20T/H||Material-touch is SUS304 stainless steel,plate type, 5℃inlet ,85°C, 15s sterilize,4℃ outlet, temperature-automatic control, with temperature recorder, CIP cleaning, Spirax sarco steam depressure and control system||1|
|B-5||High pressure homogenizer||10T/H||25MPa, including starting cabinet||2|
|C||Milk Sterilization & Filling unit|
|10T/H||SUS304 stainless steel, aseptic tye, tubular type, inlet material temperature:20 ℃, sterilizing temperature:137℃, 5S, output temperature 30℃, Simens PLC automatic touch screen control, UK Spirax Sarco steam control system, imported flow meter, frequency converter, temperature sensor, stainless steel electric control cabinet||1|
|C-2||Full-automatic vacuum degasser||10T/H||Full-automatic control, SUS304 stainless steel, differential pressure transducer imported from Germany Labom, working vacuum degree -0.64～-0.85Kpa, flow control is frequency converted type, working together with sterilizer, with condensing device||1|
|C-3||High pressure homogenizer||10T/H||25MPa, including starting cabinet, frequency conversion control||1|
|C-4||pillow filling machine||500ml/bag,6000bags/hour||1|
|C-5||pillow filling machine||1000ml/bag,6000bags/hour||1|
|D||Full automatic CIP system|
|D||Full-automatic CIP system||3×3T||Three tanks, double circulation, full-auto CIP, double layer insulation tank, tank material SUS304 stainless steel,acid & alkali tank with stirrer, PLC touch screen control, high & low liquid level alarm system, Spirax Sarco temperature auto control, JUMO temperature sensor, electricity conductivity, flow rate switch, Shanghai YUAN brand progress pump 3 pieces, 20T/H, pumping lift 36M, ABB motor, plate heater on line temperature rising, 300L concentrated acid & alkali tank, tank material is SUS316L , The USA imported pneumatic diaphragm pump two pieces.||1|
|R||CIP return pump||30T/H||SUS316L stainless steel, pump lift 24 meters, mechanical seal,||4|
|E||Water treatment system|
Water softening system
Including 20m³ water box, multi medium filter, activated carbon filter, precision filter, cartridge filter, softener, 20T pure water box, piping connection, pumps(30T, 36m), valves, constant voltage control, etc. And also including filter medium like multi medium filter silica sand, shell activated carbon etc.
|Total price for equipment|
Product piping system
|Including the CIP pipeline, processing pipeline and sewage pipeline of all the equipment from Beyond, and also all the needed valves, meters, use SMS standard||1|
|F-2||Power piping system||Including equipment steam pipeline(carbon steel pipe), ice water pipeline(Hot dip galvanized pipe), tap water(Hot dip galvanized
) and compressed air pipeline(carbon steel pipe), and also needed valves,meters, not including the insulation of the pipes, buyer connect main pipe to required position
|F-3||Electrical distribution cabinets||Including the equipments' control cabinets from Beyond in the customer's factory site(made of stainless steel), with electrical control cabinet for the CIP system, the user will need to connect the electric power supply to the control cabinets||1|
|F-4||Electric installation materials||All the needed cable and related electric parts for installation will be provided by Beyond (cable, support, flexiable tube etc)||1|
Installation and commissioning cost
|Installation and commissioning on the equipments from seller's(Beyond) company,customer offer installation tools, like electric welding machine, argon arc welding machine, cutting machine, angle grinder, cutting slices, flat machine, stainless steel wire, carbon steel electrode, electric and argon gas, etc||1|
|F-6||Staff cost||Buyer will need to provide the round-trip tickets from china to buyer's factory,pay for the accomadation for the seller's engineers during the installation and commissioning period, in addition pay US$ 100 per day for each engineer.||1|
|F-7||Freight and package cost||send to shanghai port||1|
1. Installation services
Installation services are provided for all new machines purchased. We will provide technical know-how for the smooth transition of your operation and support the installation, commissioning and operation of the machine. It will guide you how to use the machine well.
2. Training services
We can train your employees to use our machines correctly. This means that we provide customers with training on how to use the system most effectively and safely, and how to maintain the best operational efficiency.
3. After sales service
We provide preventive maintenance and after-sales service. Because we strongly feel the importance of supporting customers and the product solutions we provide. Therefore, we provide comprehensive maintenance options to prevent equipment problems. We also provide one-year warranty and lifelong technical support!
