SGS 1000LPH Egg Liquid Juice Pasteurization Equipment With Touch Screen

Place of Origin China
Brand Name Beyond
Certification CE certificate/ISO9001/SGS
Model Number BY-PP
Minimum Order Quantity 1piece
Price 24600-45000USD/Pcs
Packaging Details export standard package
Delivery Time 60-90 days
Payment Terms L/C, T/T, Western Union
Supply Ability 20 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Pasteurizer Capacity 1000LPH-10000LPH
Application Milk/Fruit Juice/Fruit Pulp/Beverage Material SUS304/SUS316
Control Semi-auto/full-auto Voltage 220V/380V/415V
Seaport Shanghai Warranty 12 Months
After-sales Services Available
High Light

SGS juice pasteurization equipment

,

PLC juice pasteurization machine

,

PLC egg pasteurization machine

Leave a Message
Product Description

Plate pasteurizer/Tubular pasteurizer/tube-in-tube pasteurizer



Application: This unit is used as Pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, ice cream etc.), and also pre-sterilize material when producing sterilized milk (long life milk).



Features:

This unit can be connected with separator, homogenizer, flash evaporator & degasser etc.



This machine has features of high heat recovery efficiency, low energy cost, compact design on the construction and easy operation, simple maintenance.



Ensure food safety
The booster pump generates a pressure difference between the pasteurization and non pasteurization sides of the device. In order to further improve safety, the differential pressure can be monitored through the pressure transmitter. If these transmitters "notice" that the differential pressure is not maintained, the product will be automatically transferred back to the balance tank for recirculation.



Process design and parameter

Production capacity: 500L-20000/H
Technical Parameter: 5℃→65℃(homogenization)→85℃(15S) →5℃
Control type: Full-automatic control (PLC with touch screen), semi automatic.





Equipment configuration

A. plate heat exchanger;

B. material-balance bucket;

C. Hot water-balance drum;

D. hot water pump;

E. product pump;

F. steam & water mixer;

G. electricity box;

H. stainless steel pipes and valves etc.

I.PLC and color touch screen;



Technical Parameter:

Model Capacity

Heat exchane

area (m²)

Total power

(kw)

Steam consumption

(kg/h)

Dimension

(L×W×H)mm

Machine weight

(kg)

BR16-BS-0.5 0.5 5 5.2 52 1200×1200×1500 790
BR16-BS-1 1 8 5.2 60 1500×1500×1800 880
BR16-BS-2 2 t/h 13 6 104 1800×2000×1800 980
BR26-BS-3 3 t/h 20 6 156 2000×2000×2200 1080
BR26-BS-4-5 4-5 t/h 30-45 8 260 2250×2000×2200 1250
BR26-BS-6-8 6-8 t/h 35-50 8 400 2250×2000×2200 1250
BR26-BS-10 10 t/h 60 11 520 2800×2000×2200 1650
BR35-BS-15 15 t/h 75 11 780 3000×2200×2200 2150
BR35-BS-20 20 t/h 80 11 945 3300×2200×2200 2350




Technical parameter: 5℃→65℃(homogenization) →85~95℃(15S) →5℃
This unit can be connected with separator, homogenizer, flash evaporator & degasser ect. This unit is used as pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, ice cream ect.) ,and also pre-sterilize material when producing pasteurized milk(long life milk).
This machine has features of high heat recovery, lower energy cost, strict design on the construction and easy operation, simple maintenance.
