Semi Auto Complete Milk Pasteurization Machine

Place of Origin China
Brand Name Beyond
Certification CE certificate/ISO9001/SGS
Model Number BY-HP
Minimum Order Quantity 1piece
Price negotiable
Packaging Details export standard package
Delivery Time 60-90 days
Supply Ability 20 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name HTST Pasteurizer Material SUS304 Or SUS316
Control Automatically Control And Semi-auto Control Voltage According To Customer's Local Voltage
Sea Port Shanghai Warranty 1 Year Or 12 Months
High Light

complete milk pasteurization machine

,

semi auto milk pasteurization machine

,

pasteurization milk extraction machine

Leave a Message
Product Description



Factory direct complete milk processing plant dairy small scale milk processing equipment



Semi Auto Complete Milk Pasteurization Machine 0



Introduction

UHT milk sterilizer
Material handling capacity: customized
Main technical features:
-Man machine dialogue, fully automatic control system, operators can work with simple training;
-With automatic alarm and fault handling system, it can effectively prevent the output of unqualified products;
-It has its own CIP system, which can realize automatic on-site cleaning. There is no need to rely on the startup of CIP system of workshop trunk road;
-There is a communication interface with the sterile packaging machine to realize the communication linkage with the sterile packaging machine and ensure the reliability of product output;
-All control components are imported famous brand products, and the control accuracy and quality are reliably guaranteed.


Pasteurized milk batch production line
parts
According to your production capacity and process requirements, the following auxiliary machines can be equipped:
Milk balance tank
Rotor pump
Pneumatic diaphragm pump
Vacuum pump
centrifugal pump


Functions of milk bag filling machine:
-Full automatic control system: the machine can automatically complete film feeding, forming and sealing, and can control every step of the whole system.
-Lower utility consumption: lower consumption of electricity, compressed air and water, which can reduce customers' costs.
-Advanced pneumatic control system: the pneumatic control system improves the wear problem of the machine and reduces the maintenance work and cost of customers.
-The high-performance air filter ensures the cleanness of the air in the filling room during the production process and greatly improves the sterility of the product.



Control elements list:

Semi-automatic control configuration Item Brand or supplier
Controller Siemens LOGO
Reducer valve Spirax Sarco from UK
Temperature control system Burkert or Spirax Sarco
Temperature transducer Labom from Germany
Temperature recorder without paper Anthone
Pipes and valves Shanghai Yuanan
Hot water pump From Italy
Precision of temperature control is ±0.5 degree



Full automatic control configuration Item Brand or supplier
Controller Siemens Touch-screen PLC
Reducer valve Spirax Sarco from UK
Temperature control system Burkert or Spirax Sarco
Temperature transducer Labom from Germany
Pipes and valves Shanghai Yuanan
Hot water pump From Italy
Precision of temperature control is ±0.5 degree

Parameter

Model Capacity Heat exchange area(m²)

Power

(kw)

Steam consumption

(kg/h)

Dimension

(L×W×H)mm

Machine weight

(kg)

BR16-UB-1 1 t/h 10 5.2 120 1500×1500×1800 980
BR16-UB-2 2 t/h 18 5.2 210 2200×2000×1800 1050
BR26-UB-3 3 t/h 26 6 280 2400×2000×2200 1450
BR26-UB-4-5 4 -5t/h 32-40 6 340 2600×2000×2200 1680
BR26-UB-6-8 6 -8t/h 35-50 8 400 2800×2000×2200 1720
BR26-UB-10 10t/h 60-70 11 450 2800×2000×2200 1720
BR26-UB-15 15t/h 70-75 15 550 2800×2000×2200 1720
BR26-UB-20 20t/h 75-80 15 620 3000×2000×2200 1720


Semi Auto Complete Milk Pasteurization Machine 1

Semi Auto Complete Milk Pasteurization Machine 2

Minimize product loss
The intelligent balance tank configuration can discharge the maximum amount of water before the product enters the tank, so as to reduce the mixing of water and product. This method reduces the number of liters in the mixing stage by more than 50%, which significantly reduces the product loss.


Semi Auto Complete Milk Pasteurization Machine 3Semi Auto Complete Milk Pasteurization Machine 4Semi Auto Complete Milk Pasteurization Machine 5Semi Auto Complete Milk Pasteurization Machine 6
