Elaboracion Industrial Yogurt Production Line 2000LPH - 10000LPH

Place of Origin China
Brand Name BEYOND
Certification ISO9001
Model Number BY-2T
Minimum Order Quantity 1 set
Price USD 100000-600000USD/ set
Packaging Details standard exporting packing
Delivery Time 50-80working days
Supply Ability 100sets per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Cow Milk, Kamel Milk, Buffalo Milk ,etc End Product Pasteurized Milkyogurt/ Cheese/cream/ Butter
Processing Capacity 2000LPH-10000LPH Control Type Semi-automatic Or Full Automatic
Package Type Plastic Pouches/ Bottles/ Cups Product Name Oat Milk Processing Line
Blending System Full-auto Blending System CIP Full-auto CIP System
High Light

Elaboracion Yogurt Manufacturing Machine

,

Industrial Yogurt Production Line

,

2000LPH Yogurt Production Line

Leave a Message
Product Description

Yogurt manufacturing machine yogurt production line yogurt elaboracion industrial





Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 0



BEYOND Machinery is a leading supplier, manufacturer and exporter of yogurt processing lines. Yogurt is one of the healthiest foods or dairy products. Many people like to add this food to their food. It also helps digestion. Even healthy and delicious drinks can be produced from such products, such as buttermilk. Therefore, the yogurt production line is also an important part of the factory. In order to process these products, they need some high-end working equipment, which can only be transported from time to time through food processing machines.



This is why it is important to find the right yoghurt production line supplier, because negligence or mistakes at the production end may bring risks and damages. However, on the other hand, when you seek the support of reliable yoghurt processing line exporters, you can relax because they are experienced in this field and can help you complete the whole process in the best way. The first thing we need to do is to focus on the perfect manufacturing and production of machinery, so that we can avoid repeated work or transformation in the later stage. Then, we will focus on the details of the equipment to make it suitable for implementation. Then, it will safely deliver to customers from all over the world with the most cautious attitude. This is why you should choose a reliable yoghurt production line manufacturer for your factory. If you are looking, please contact us.



Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 1





Equipment list of 25T/D DAIRY PRODUCTION LINE
(pasteurized milkyogurtcheesecreambutter)
NO. NAME MAIN TECHNOLOGY PARAMETER
1 MILK RECEIVESTORAGEAND CREAM SEPARETOR UNIT
2 electron pound scale maximum weighing 500KG
3 milk weighing tank made of SUS stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball
4 milk acceptor SUS304 stainless steel,single layer,CIP cleaning ball
5 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
6 twin piping filter SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh
7 dish separator auto residue discharge
8 chiling tank SUS304 stainless steel,alveolate jacket,attached with compressor
9 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
10 PREPARING UNIT
11 blending tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
12 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
13 mini set of plate-type heat exchanger SUS304 stainless steel,two stages,
14 high speed emulsification tank SUS304 stainless steel,heat insulated,bottom high speed emulsifier,digital readout thermometer,supporters with adjustable feet
15 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
16 twin piping filter SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh
17 sterilizing,homogenizing unit
18 UHT sterilizer tub-type,sterilzing temperature 137 C,holding time 4S,full automatic control
19 high pressure homogenizer 40MPa,(starting box included)
20 temperature holding SUS304,holding 300S
21 distributing plate SUS304,3 holes
22 cheesebutter processing unit
23 bufferying tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
24 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
25 cream seperator
26 bufferying container SUS304,with cover
27 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
28 butter-churner SUS304,stepless timing
29 cheese vat SUS304,with heating jacket and insising device
30 pressor SUS304,6 heads
31 mould SUS304,10L,with cover
32 yogurt fermentation unit
33 fermentation tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
34 rotary pump SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift
35 plate cooler SUS304,single stage,milk discharge at 4C
36 rotary pump SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift
37 filling unit
38 higher position tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
39 pasteurized milk filling machine
40 yogurt filling machine
41 CIP system
42 semi-auto CIP system outer coat of SUS304 stainless steel material,inner shell of SUS316,single cleaning way,Concentrated acid/alcali tank adding system based on US technology, 100L×2 acid/alcali Concentrate tanks
43 CIP return pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
44 installation part whole milk processing line installation and commissioning





Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 2Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 3



The company is specialized in manufacturing yoghurt processing lines and producing food equipment and machines. Our food production line machines have been exported to many countries, from China to Egypt, Sudan, Kenya, India, the United States, Russia, Canada, Australia, the United Kingdom, Malaysia and Indonesia. Chinese manufacturer of yogurt processing line, which can be customized according to specifications.



Yogurt processing line manufacturers in China, and yoghurt processing line suppliers in China food processing plants and companies.



Related food machinery and production line equipment

We provide comprehensive solutions for dairy processing, fruit processing, pet food processing and biopharmaceutical processing. An integrated solution designed for your food business. We design and build customized food processing and food packaging production lines to help you provide customers with better processing machines and products. These production lines have integrated functions from beginning to end. Other highly specialized food processing machines, such as yogurt processing plants.



Service flow chat



Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 4



Get in touch

If you are passionate about the food industry and understand the importance of food processing and want to feed the world, you have many reasons to keep in touch with us. As the best supplier of food processing machines and equipment, we are ready to help you.



Build your factories and factories with the most advanced food processing machines, and watch your business grow at a speed you never thought possible.




Company information
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 5
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 6
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 7


Our services
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 8


Trade shows
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 9


Certificate
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 10


Packaging & Shipping
Elaboracion Industrial Yogurt Production Line  2000LPH - 10000LPH 11



FAQ


1 ) Q: How can we visit your factory?
A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.



2) Q: How do you ensure the quality of your products?
A: Our Company is a state owned enterprise with more than 16 years experience , strict operation policy is performed, advanced processing machines guarangtee the precision of all components, workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand. Series of test and inspection are done in the whole producing state.



3) Q: What payment methods your company accept?
A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .



4) Q: How long is the warranty time for your products?
A: Our officially promised warranty time is 12 months after commissioning .



5) Q: I am new in this field,can you supply us turnkey services?
A: YES.We can supply all the system including Market Analysis/Product Analysis/Location Choice/Processing Flow Design/Equipment Layout Design/Building Design direction/Equipment mode selection/Equipment Manufacturing/Equipment Mounting/Equipment Debugging/Worker Training.


6) Q: I haven't done business with you company before, how can I trust your company ?
A: Our company has been in Alibaba.com for 14 years, which is longer than most of our fellow suppliers, we have been golden suppliers for years. What ' s more, we have got quite a lot authority certificates, for example, CE, ISO9001, Alibaba onsite check certificate.



7) Q: What ' s the shipment terms and delivery time of your company?
A: Well, the delivery time depend on the quantity of your order. Usually is 20 days . For some customized machine 30 days is necessary.



8) Q: Can you supply OEM services?
A: Yes,we have our R&D team,and we have more than 400 workers with workshop area 75000 square meters.



9) Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
