2000L Cheese Making Machine Touch Screen For Dairy Field
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| MATERIAL | Sus304 Sus316l | Capacity | 500L/1000L/1500L/2000L |
|---|---|---|---|
| Power | 50KW | Application | Dairy Field, Specially For Producing Cheese. |
| High Light | 2000L Cheese making machine,dairy field Cheese making machine,touch screen Cheese making equipment |
||
Product Description
Cheese making machine Automatic Cheese Making Equipment Processing Production Line
Cheese making machine automatic cheese making equipment processing production line
Milk processing line
Factory capacity: 2-300 tons / day.
Product type: 1 or more than 2.
Milk processing line
1. Milk collection or powder dissolving mixing section
2. Stirring and sugar melting part
3. Pasteurizer and homogenizer
4. Milk storage or yogurt production plant
5. Filling or packaging device
6. CIP cleaning system
7. After treatment equipment, such as conveyor, packaging or tray, etc.
8. Use other auxiliary equipment, such as steam boiler, air compressor, chiller, etc.
9. Provide installation materials for material pipes, non material pipes and electrical installation
technological process:
1. Raw milk storage
2. Filter
3. Preheating
4. Separation
5. Homogenization
6. Temporary storage
7. Disinfection
8. Precooling / fermentation
9. Stir (cheese jar)
10. Pressing and forming
11. Cutting or packing
| A. Application: Cheese vat is used in dairy field, specially for producing cheese. It is the necessary equipment for processing different kinds of cheese. |
|||||||
| B. Working flow: Milk enters into the vat from the inlet through the filter, they are heated and fermented in the vat, further stirred and cut. Then the whey from fermented milk is discharged from the outlet, the cheese is remained in the vat. |
|||||||
| C. Features: 1. With jacket for heating and temperature keeping, or cooling to certain temperature for the milk become rigid 2. Parts contacting with product are all made of high grade stainless steel, comply with food grade sanitary standard. 3. With temperature control system, auto control the agitator, auto press the cheese to drain the milk whey 4. Evenly cutting and stirring, whey is highly separated. |
Parameter and machine list:
| No. | Name | Model | Technical |
| 1 | Cheese vat | 500L | 1. Materia:SUS304; 2. Triple layers with PU as insulation and dimple pad jacket for heating and cooling; 3. Ellipse shape, 4. Two agitators,one is for mixing, the other one is for cutting cheese to small pcs; 5. Agitator is able to move from one end to another; 6. Temperature auto control panel; 7. Auto discharge whey outlet etc. 8. Electric power: 380V,50HZ, 3phases; if other requirement can be customized EXW price shanghai factory |
| 2 | Cheese vat | 1000L | 1. Material: SUS304 stainless steel 2. With dimple pad jacket and PU insulation 3. Two agitators, one is for mixing, the other is for cutting cheese into small pieces. Agitators are able to move from one side to the other 4. Temperature automatic control panel, automatic discharge whey outlet 5. The cheese vat platform will be prepared by user; 6. Electric power: 380V,50HZ, 3phases; if other requirement can be customized EXW price shanghai factory |
| 3 | Cheese vat | 1500L | 1. Material: SUS304 stainless steel 2. With dimple pad jacket and PU insulation 3. Two agitators, one is for mixing, the other is for cutting cheese into small pieces. Agitators are able to move from one side to the other 4. Temperature automatic control panel, automatic discharge whey outlet 5. The cheese vat platform will be prepared by user; 6. Electric power: 380V,50HZ, 3phases; if other requirement can be customized EXW price shanghai factory |
*Duration of Guarantee:
1. within 12 months since the installation and commissioning of equipment are finished, If the defects of equipment and spare parts result from the seller, the seller will supply spare parts and maintenance by free of charge. If the defects result from the buyer’s improper use of equipment, seller will charge the cost of maintenance and spare parts.
2. After 12 months since the installation finished, if the equipment and spare parts are defected, the seller will charge the cost of maintenance and spare parts.
3. If Buyer request Seller and engineer to Buyer's factory, buyer should supply seller’s workers the round trip air tickets and $80 dollars for each worker per day. And the local traffic, accommodation and lodging fees should also be available.
*installation terms:
1. 50-60 days for installation and commissioning.
2. BEYOND CO., provide installation, commissioning of all equipment supplied by BEYOND CO., as stated in the quotations.
3. buyer provide round way air tickets,local traffic , room and board,in addition pay $100 per day for each engineer.
Beyond's mold cleaning machine can clean cheese molds, lids, nets, crates, barrels and other items very efficiently.
Die washer
Manual mold cleaning machine is used to clean a small amount of cheese mold. To start the cleaning procedure of the mold cleaning machine, just close the cover of the machine. Once the selected time has passed, the cleaning of the cheese mold will stop automatically.
Of course, our die cleaning machine is equipped with automatic cleaner and heating system, and can also be integrated into the fully automatic die stamping / processing system.
Simple quick shelf cleaning machine
The cheese rack in the storeroom is cleaned every week. Therefore, we have developed a shelf cleaning machine.
With this shelf cleaning machine, cleaning the cheese shelf is simple and fast.
Our shelf cleaning machine reduces labor costs, but also reduces the consumption of water and detergent solution.
