300kg Industrial Strawberry Washing Machine For Fruits Vegetables Processing

Place of Origin China
Brand Name Beyond
Certification ISO9001:2015
Model Number 2-20TPH
Minimum Order Quantity 1 set
Packaging Details Wooden package and Frameworks;Container Loading;PE Film Wraps
Delivery Time 30 days after payment
Payment Terms L/C, T/T
Supply Ability 30 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Machinery Function Washing And Cleaning Output Product Name Fruit And Vegetabbles Raw Materials
Applicable Industries Manufacturing Plant, Food & Beverage Factory, Food & Beverage Shops Voltage 220V/380V
Power(W) 2-5KW Dimension(L*W*H) 3000*800*1200mm
Weight 300kg-1000kg After-sales Service Field Installation, Commissioning And Training
Application Fields Fruit Processing Plant, Vegetable Processing Plant, Beverage Factory,Fruit Juice Plant Capacity 2-20TPH
Control Type Full-automatic Name Strawberry Cleaning Machine
High Light

Industrial Strawberry Washing Machine

,

Automatic Strawberry Washing Machine

,

Vegetable Processing Machine 300kg

Leave a Message
Product Description



Fruits and vegetables cleaning machine automatic industrial strawberry cleaning machine



300kg Industrial Strawberry Washing Machine For Fruits Vegetables Processing 0

Introduction


The strawberry cleaning line can clean fresh strawberries and then air dry them at room temperature without damaging the strawberry peel. The cleaning line is also suitable for all kinds of berries, fruits and vegetables with similar shapes.



Characteristics of strawberry cleaning line

▼ the material is food grade stainless steel, with exquisite workmanship and durability.

▼ powerful cleaning and removal of deposits on the surface.

▼ Bubble + high pressure + brush cleaning, various cleaning methods.

▼ automatically deliver and lift the spray to ensure the cleaning effect.

▼ the air drying system will not damage the skin of strawberries at room temperature;



300kg Industrial Strawberry Washing Machine For Fruits Vegetables Processing 1

Technical parameter(refer to the raw fruit processing capacity)

Model Description External dimension
(L×W×H)(mm)
Suggested capacity Suggested power(kw)
capacity and power varies as to
 different fruits
GQXJ-2 Material: sus304 stainless steel ,speed is step-less adjustable, with air fan and compressing pump 3000*800*1200 ≤2(T/H) 2.2
GQXJ-5 3500*1000*1200 3~5(T/H) 3
GQXJ-10 5000*1100*1200 6~10(T/H) 4.4
GQXJ-15 5000*1300*1200 11~15(T/H) 5.5
GQXJ-20 5000*1500*1200 16~20(T/H) 5.5



300kg Industrial Strawberry Washing Machine For Fruits Vegetables Processing 2

Condition: New
Brand name: Shanghai Beyond;
Type: whole processing Line/turnkey project/fruit and vegetables processing/dairy processing/beverage processing
Voltage: 220v/380v
Power(W): 100-200kw
Weight: Different size different weight/customized
Dimension(L*W*H): Different size different dimension/customized
Certification: CE&ISO
Warranty: 12 months/1 year
After-sales Service Provided: Engineers available to service machinery overseas
Main material: SUS304 or SUS316
Control type: automatic, semi-automatic
energy consumption: Low consumption with high efficiency
capacity: 500-10000L/H-customized
installation period: 1-3months
Period time: 30 days-120 days
Cups material: pouches, paper box, glass bottle, pet bottle, glass bottle
Product storage condition: room temperature; low temperature;



300kg Industrial Strawberry Washing Machine For Fruits Vegetables Processing 3





How to clean strawberries

Strawberry cleaning line mainly includes bubble cleaning, brush roller cleaning and air drying. Each machine has its specific functions and features to clean strawberries. The following is the details.



There is a bubble device to make the strawberries roll and remove the effects of soil, sand, dust and pesticide residues on the surface;

The filtered water is pumped into the main water tank through the circulating water pump to realize the recycling of water, save energy, environmental protection and sanitation;

The spray pipe at the upper part of the lifting part always supplies water, so that the sewage in the water tank is gradually replaced



Strawberry brush drum washing machine

The brush roller is driven and rotated by a chain driven continuously variable transmission. At this time, the strawberry moves towards the outlet while rotating on the brush roller, and the nozzle at the top sprays the strawberry at the same time.

The machine has the characteristics of good washing effect, strong pest elimination ability, reasonable structure, simple operation and convenient connection.



Strawberry air dryer

The cleaned strawberries are transported through the conveyor belt, and the air flow generated by the air dryer is ejected through the nozzle. The dry air temperature is normal temperature, and the air dryer can effectively protect the color and quality of strawberries.

Here is our strawberry cleaning air drying packaging line test in our factory for your reference!!!

Compared with the traditional drying and dehydration method, the air dryer has the advantages of simple operation and convenient use (it can be used only by connecting the power supply)! The removal rate of water is high (up to 99%), and there is no scale pollution on the packaging surface.



Packaged strawberries

After cleaning and drying strawberries, we can also support strawberry preservative film packaging machine. The automatic fresh-keeping film packaging machine can be upgraded at will, combined with weighing and labeling functions, and record the background data in real time, so as to view the parameters of each packaged strawberry. Strong brand machine, high packaging effect, consumers feel more at ease.
