SUS304 Automatic Juice Extractor Machine For Apple pulping

Place of Origin SHANGHAI CHINA
Brand Name BEYOND
Certification ISO
Model Number 5TPH-10TPH
Minimum Order Quantity 1PCS
Packaging Details Wooden case/Steel frame standard export package
Delivery Time 60-90 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 200PCS per year
Product Details
Name Apple Juice Machine Capacity 5TPH-10TPH
Material SUS304/SUS316 Applied Fruit Orange/Lemon/Citrus
Function Juice Extracting And Pulping Control Type Full-auto
Usage Fruit Juice Processing Line Keywords Lemon Juice Extractor Extractor Industrial De Jugo De Naranja Planta De Procesamiento De Jugo De Fruta
High Light

Automatic Juice Extractor Machine

,

SUS304 Juice Extractor Machine

,

Pulping Apple Juice Machine

Leave a Message
Product Description

              Juice extractor machine industrial automatic apple juice machine



The automatic Apple Juicer can process 500kg fresh apples into apple juice every hour. You can store apple juice for a long time. It tastes good and loses very little nutrients.



Application of apple juice Juicer

The machine is suitable for crushing berry fruits and vegetables, as well as ripened and softened nuts and vegetables. The crushing particle size is 3 ~ 8mm. Then, the crushed materials are sent to the screw system to improve the juicing effect.

Fruits: pineapple, apple, pear, mulberry, grape, orange, etc.

Vegetables: tomato, ginger, garlic, celery, etc. Different fruits or vegetables have different processing capacity, and the processing capacity in the parameters depends on tomato.



SUS304 Automatic Juice Extractor Machine For Apple pulping 0



Automatic apple juice machine function

▼ mesh diameter: 0.6mm; Fully automatic machine

▼ the apple Juicer has both the function of crushing various fruits and the function of juicing.

▼ automatic separation of slag discharge and juicing.

▼ high juice extraction rate and make full use of raw materials

▼ this machine is small and easy to operate and move.

▼ the machine is made of 304 stainless steel




Structure of fresh apple juice machine

The machine is mainly composed of crushing equipment in the feed hopper, front support seat, screw, filter screen, juicing device, back seat, slag nozzle, etc.



SUS304 Automatic Juice Extractor Machine For Apple pulping 1



SUS304 Automatic Juice Extractor Machine For Apple pulping 2



Machine capacity

300-320 pcs/mins

Juice extracting rotor drum

2 pcs
Extracting heads 7 pcs/ drum
Motor power 5.5kw, 960r/min
Machine size 1700×1670×1600mm(Length×Width×Height)
Machine net weight 2T



It adopts the foreign advanced technology, can be applicable for fresh juice extracting from tangerine, orange, grapefruit, lemon, etc., and avoid the bitter vegetable oil remained in fruit cells and residue from fruit peels.This machine is composed of the parts: machine frame, gear box, juice collecting bucket, left rotor drum, blades, 4-opens rotary tables, right rotor drum, bowl-shape conveyor, safety cover, driving motor, etc. The working theory is the motor drives the main shaft through the V-belt pulley, the main shaft will transfer the power to the following structures: bowl-shape conveyor, 4-opens rotary tables, left rotor drum, and right rotor drum.

SUS304 Automatic Juice Extractor Machine For Apple pulping 3





How to make apple juice

1. When putting the apple into the feed hopper, first crush the apple, then the crushed apple is spiral pressurized, and the extracted fruit juice flows into the fruit juice container through the strainer.

This is the video of our apple juice machine working in our factory for your reference!

The waste will be discharged through the annular gap formed between the screw and the pressure regulating conical part.

2. Through the axial movement of the pressure regulating head, the size of the interval can be adjusted to adjust the juice yield.

After you finish making apple juice, your first consideration may be how to extend the shelf life of apple juice. Our sterilized filling machine can solve this problem for you, and the sterilized and filled apple juice is easier to store, which can bring more benefits to your juice processing business!




Of course, we can also provide you with the turnkey project of apple juice production line according to your specific needs. If you have any questions about Apple's handling, please feel free to leave us a message!



SUS304 Automatic Juice Extractor Machine For Apple pulping 4
