Product Details
Name Fruit Conveyor For Sale Material Stainless Steel
Voltage According To Customer Local Voltage Power Consumpiton Energy Saving Type
Warranty 12 Months Application Used For Fruit Conveying
High Light

Fruit Conveyor Washing Machine

,

Automatic Fruit Processing Washing Conveyor

,

Industrial Fruit Washing Conveyor
Leave a Message
Product Description

Fruit conveyor for sale automatic industrial fruit washing conveyor



Industrial Fruit Processing Equipment Automatic Fruit Washing conveyor 0



In the process of fruit processing, the position needs to be constantly changed. We have developed a fruit conveyor. This fruit conveyor has the advantages of fast transportation speed, simple operation, suitable for the complex production situation of high drop and large angle transportation, and can work stably for a long time. The fruit conveyor meets the health and safety industry regulations of food production.



We have expertise in designing and manufacturing fresh fruit and vegetable processing plants equipped with the necessary machinery and material handling machinery for proper processing and final packaging. These plants are integrated with a series of interconnected machines, allowing them to operate automatically and continuously with minimal manual intervention. The fruit conveyor can be used alone or integrated into the production line of the fruit processing plant.



Industrial Fruit Processing Equipment Automatic Fruit Washing conveyor 1



Technical parameter

Model Description

Transportation capacity

(based on Apple)

 Motor power (kw)
Line speed Capacity
GBTS-S400

The supporter is made of SUS304 stainless steel,

the clapboard is made of SUS 304 or plastic;

moving speed is adjustable

 0.1-0.4m/s 2.5-4(m³/H) 2-5m 0.55
6-10m 0.75
GBTS-S600 0.1-0.4 m/s 4-6(m³/H) 2-5m 1.1
6-10m 1.5
GBTS-S800 0.1-0.4 m/s 6-8(m³/H) 2-5m 1.5
6-10m 2.2
GBTS-S1000 0.1-0.40 m/s 8-10(m³/H) 2-5m 1.5
6-10m 2.2
GBTS-S1200 0.1-0.4 m/s 10-15(m³/H) 2-5m 1.5
6-10m 3
GBTS-S1400 0.1-0.4 m/s 15-20(m³/H) 2-5m 2.2
6-10m 4


Industrial Fruit Processing Equipment Automatic Fruit Washing conveyor 2

Industrial Fruit Processing Equipment Automatic Fruit Washing conveyor 3



Technical Parameter:
Name Description Transportation capacity (kw)
Power
line speed Capacity
GBTS-S400 the supporter is made
of SUS304 stainless steel,
the clapboard is
other SUS304 stainless
steel or plastic,
speed is adjustable		 0.1-0.4m/s 2.5-4m3/H 2-5m 0.55
6-10m 0.75
GBTS-S600 0.1-0.4m/s 4-6m3/H 2-5m 1.1
6-10m 1.5
GBTS-S800 0.1-0.4m/s 6-8m3/H 2-5m 1.5
6-10m 2.2
GBTS-S1000 0.1-0.4m/s 8-10m3/H 2-5m 1.5
6-10m 2.2
GBTS-S1200 0.1-0.4m/s 10-15m3/H 2-5m 1.5
6-10m 3
GBTS-S1400 0.1-0.4m/s 15-20m3/H 2-5m 2.2
6-10m 4



Industrial Fruit Processing Equipment Automatic Fruit Washing conveyor 4



Application:

Receive the product and lift it from the ground and transport it to the next required machine height. It is usually used as part of a continuous processing plant.



technological process:

Fruit and vegetable products are sent to the feed hopper of the elevator. It transfers heat to the drive belt. The conveyor belt moves along the conveyor belt and unloads the product to the next machine at the required height.



Contents:

Thermal drive belts provided by internationally renowned suppliers

The body frame is made of stainless steel 304 square tube and plate. The plate is laser cut to obtain a precise shape and provide the correct belt direction. The square tube is welded on the plate to provide a tubular structure for the machine for easy cleaning

The body adopts modular structure, including bottom, top and middle

The conveyor belt of modular belt made of high-quality stainless steel bracket is installed on the precisely cut conveyor belt. The bracket is installed directly on the cutting belt. The conveyor belt is composed of steel belt, roller, sliding shoe, etc., which is used to guide the conveyor belt along the required path

The return side is made of steel strip and is properly positioned

Gear motor, square shaft, sprocket, bearing and appropriate driving device.
