Fully Automatic SUS304 Coconut Oil / Water Processing Plant 2TPH - 20TPH

Coconut oil processing plant coconut water processing plant coconut water processing machine

Coconut is a kind of nutritious fruit, which is planted in different parts of the world. Every year, people can harvest a lot of coconut. Coconut processing line can add coconut into a variety of fruit products. Coconut is rich in fat and nutrition. Dried coconut meat contains 3.4% - 4.0% protein, 30% - 40% fat and dried coconut powder contains 50% - 70% oil. In addition, coconut meat also contains carbohydrates, fiber, minerals, vitamins and other nutrients. Coconut water is a high-grade refreshing drink, containing 0.1% protein, 0.1% fat and 4% carbohydrate.

Coconut processing line includes coconut soaking system, coconut water extraction, filtration and pasteurization system, coconut meat cleaning, bleaching, sorting and coconut milk extraction system, coconut milk mixing, sterilization and scattering system, coconut juice evaporation, sterilization and filling system, CLP cleaning system and RO aquatic system.

Application Scope:

Details of coconut milk production line

Raw material: Coconut

Final product:

Coconut juice, coconut milk, coconut water and coconut powder

Capacity: 500kg / h-10t / h, customized

Packaging material: adjustable

Volume: adjustable

Package: tin can / PET / Tetra Pak/

This coconut production line has high flexibility, and can produce coconut cream and coconut mlk, single concentration and concentrated coconut water, virgin coconut oil and deionized coconut. By adjusting the process flow chart and machine, coconut powder. According to customer requirements, sterile bags, tin cans, bottles and other consumable packages can be used to package coconut products. The available capacity of coconut processing line is 500 to 10000l / h.

Process of coconut processing line

The production process of coconuts is very simple. First, clean the coconuts, then send the broken coconuts to the conveyor belt, let the coconut pulp reach the designated position through the elevator, then cut the coconuts half for juice, send the coconut pulp to the designated position, use the elevator to send it to the entrance of the crusher, break the coconut pulp, enter the colloid mill, send the processed coconut pulp to the receiving tank, and then filter the coconut pulp, Coconut oil is extracted by three-phase dish separation, and then other pulp is sent to the buffer tank. The pulp is matched with other auxiliary materials through the ingredient tank, then processed by the filter, deaerated by the degasser and homogenizer, and then sterilized by the sterilizer at high temperature. The pulp and juice are packed and delivered by the filling machine.

Characteristics of coconut processing line

Advanced technology and energy conservation.

SUS304 / 316L material, international brand high-quality parts.

Provide semi-automatic and fully automatic systems.

Customized turnkey solution, including installation and commissioning.

The finished product has excellent quality and delicious color.

High production efficiency, flexible production, can be customized according to customer needs.

Complete monitoring system with control room to monitor each processing stage.

Daily output can be clearly displayed.

PARAMETER

Cleaning system of coconut processing line

All equipment of the coconut processing line is designed according to international food grade requirements and is completely cleaned by using integrated cleaning procedures and systems or centralized fully automatic CIP system. This advanced integrated cleaning system can clean the equipment of the whole processing line and quickly restore it to the state of initial preparation for production.

Service flow chart

The coconut processing line can be designed and manufactured according to the needs of customers, so as to ensure that the coconut processing line can meet the production needs of customers. The coconut processing line adopts advanced technology and high-quality materials, and its maintenance and operation are very simple at ordinary times. It can realize automatic and efficient production, realize the return on investment of manufacturers in the shortest time, and occupy a favorable market position through high-quality products.
