Industrial Beverage Production Line Tea Drink Making Machine Customized Design

Place of Origin Shanghai,China
Brand Name Beyond
Certification ISO9001:2008/HACCP/GMP
Model Number 2-100T
Minimum Order Quantity 1 set
Packaging Details 1.the equipments will be firstly wrapped by plastic film. 2.we will make stainless steel supporter with styrofoam on it under the equipments. 3.and last the equipments will be put in wood crates.
Delivery Time 40 work days
Payment Terms L/C, T/T
Supply Ability 10 Unit/Units per Month Days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Processing Line Condition New
Voltage 380v 50hz Weight 100kg-5000kg
Dimension(L*W*H) Special Power(W) 36kw
Turnkey Project Whole Line Processing Types Milk
Warranty 1 Year
High Light

beverage filling machine

,

beverage processing equipment

Leave a Message
Product Description

Industrial Beverage Production Line Tea Drink Making Machine Customized Design

Industrial Beverage Production Line Tea Drink Making Machine Customized Design 0



tea beverage processing plant :
1. turnkey project
2. semi-automatic or fully automatic
3. customized design
4. automatic

Industrial Beverage Production Line Tea Drink Making Machine Customized Design 1

Description of tea beverage processing plant

this tea beverage production line produce several types of tea beverage, i.e. black tea, green tea, Herbal tea and so on.



This tea beverage production line raw milk can be tea leaves or tea powder or tea concentrate, sugar, stabilizer and flavors etc. the procedure method can be blending-UHT sterilizer-homogenizer-hot filling- cooling tunnel- pacakge and so on.

Industrial Beverage Production Line Tea Drink Making Machine Customized Design 2

Plant beverage clarification and homogenization
Due to the need for clarified and transparent juice,some plant beverages requir clarification during the production process to remove suspended solids in the juice.Usaually need to use a centrifuge to clarify.

Plant beverage sterilizing and filling
According to the composition characteristics of plant beverages,different sterilization processes can be used,generally high-temperature short-term sterilization or ultra-high temperature instantaneous sterilization process is adopted.The homogenized material is sealed and filled,and sterilized at 121℃ and pressure 2kpa for 15-20min.For heat-sensitive and nutrient-containing plant beverages,they can be filled into containers after sterilization at 130-140℃ and 3-4S.

Industrial Beverage Production Line Tea Drink Making Machine Customized Design 3

End product package of this tea beverage production line can be plastic pouches, plastic cups, plastic bottles, glass bottles, roof top box, pre-pak pouches , etc. for this fruit juice production line according to different end product and package type, the production technology is differently designed, but commonly include the following steps:



No. Flow No. Name Model Main technical parameter QTY Manufacturer
1 A     Extracting unit
2 A-1 Extracting tank 1000L SUS304,jacket, pearlite insulation, breath valve, CIP washing ball, water inlet, feeding man hole,defoaming mouth, with near switch, stainless steel mesh, Pneumatic locking device,air cylinder use the brand of AirTAC,Shanghai YuAn vales, digital thermometer,Jumo temperature sensor 3 BEYOND
3 Rotating joint DN32 SUS304,can endure high-temperature 3 BEYOND
4 Temperature sensor PT100 SUS304,4-20mA signal output,length 100mm 3 BEYOND
5 magnetism sensor switch   Equip with extracting tank air cylinder 12 BEYOND
6 A-2 Centrifugal pump 3T/H SUS304 stainless steel, 24 meters lift, mechanical seal 3 BEYOND
7 A-3 Tubular heater 3T/H SUS304, tubular type, steam heating directly,PTFE sealing,withstand voltage 0.8mpa, Δt=20 degree 3 BEYOND
8 A-4 Steam control system   DN40 SpiraxSarco pressure reducing valve, DN25 steam regulating valve, DN15 SpiraxSarco drain valve, Jumo temperature sensor, Domestic well-known brands instrumentation 3 BEYOND
9 A-5 Twin barrel filter 3T/H SUS304 stainless steel, 80M,twin tubes 3 BEYOND
10 A-6 Centrifugal pump 3T/H SUS304 stainless steel, 36 meters head of delivery, mechanical seal 1 BEYOND
11 A-7 Twin barrel filter 3T/H SUS304 stainless steel, 150M,twin tubes 1 BEYOND
12 A-8 Twin barrel filter 3T/H SUS304 stainless steel, 200M,twin tubes 1 BEYOND
13 A-9 Palte cooler 3T/H SUS304, plate Proof Pressure 0.8MPa,60-20℃ 1 BEYOND
14 A-10 Operating platform   stainless steel pattern plate, handrail, ladder, centralized drainage,size 5000*4000*3000mm 1 BEYOND
15   Subtotal
16 B     Blending unit
17 B-1 Temporary storage tank 2000L SUS304 stainless steel, single layer,off-center agitator, 36 rpm, airtight manhole, digital display thermometer, CIP cleaning ball, adjustable legs, sample valve 3 BEYOND
18 B-2 Centrifugal pump 3T/H SUS304 stainless steel, 24 meters lift, mechanical seal 2 BEYOND
19 B-3 Seperator 3T/H Two phase seperation, auto residue discharge, with stainless steel control box 1 BEYOND
20 B-4 Twin barrel filter 3T/H SUS304 stainless steel, 10u,twin tubes 1 BEYOND
21 B-5 Twin barrel filter 3T/H SUS304 stainless steel, 5u,twin tubes 1 BEYOND
22 B-6 Twin barrel filter 3T/H SUS304 stainless steel, 5u,twin tubes 1 BEYOND
23   Subtotal
24 C Sterilizing and filling unit
25 C-1 Tubular sterilizer Q=2.5T/h

Material: SUS 304 tubular type, Sterilization temperature range: 40--125(15S)(sterilization)--88℃(hot filling) Spirax sarco steam pressure relief and regulating valve system, steam trap, Germany Jumo temperature sensor. Germany Burkert tower water regulator, GEA/APV pneumatic valve, paperless temperature recorder,Siemens PLC touch screen control, with self CIP cleaning system
