High Efficiency Dairy Processing Machines , Milk Production Line

Place of Origin China
Brand Name BEYOND
Certification ISO9001
Model Number BY-2T
Minimum Order Quantity 1 set
Price USD 100000-600000USD/ set
Packaging Details standard exporting packing
Delivery Time 50-80working days
Supply Ability 100sets per year
Product Details
Application Cow Milk, Kamel Milk, Buffalo Milk ,etc End Product Pasteurized Milkyogurt/ Cheese/cream/ Butter
Processing Capacity 2000LPH-10000LPH Control Type Semi-automatic Or Full Automatic
Package Type Plastic Pouches/ Bottles/ Cups Product Name Soy Milk Production Line
Blending System Full-auto Blending System CIP Full-auto CIP System
High Light

Milk Production Dairy Processing Machines

,

2000LPH Dairy Processing Machines

,

2000LPH Milk Production Line

Leave a Message
Product Description

High Efficiency Dairy Processing Machines/Milk Production Line



High Efficiency Dairy Processing Machines , Milk Production Line 0



Leading manufacturer of dairy processing equipment



We are committed to becoming one of the best dairy machinery manufacturers through our turnkey project solutions, covering the following areas:



Liquid milk processing, standardization, homogenization and storage

Pasteurized cream / standardization and cream processing

Full automation of dairy industry

Curd and cream milk processing and packaging line

Yogurt (stirring and solidification), Greek yogurt processing plant

UHT and aseptic storage of dairy products

White butter and butter factory

Ice cream mixing processing plant

Cheese processing line

Modernization of process and equipment

Local cleaning (CIP system)



High Efficiency Dairy Processing Machines , Milk Production Line 1

Liquid milk processing, standardization, homogenization and storage
We design, design and provide complete devices, processing lines and equipment for the treatment of raw milk, as well as for the manufacture, filling and packaging of pasteurized bagged milk, sterile UHT milk, as well as milk based products of curd milk, RASI milk, yogurt (all types), mistidoshi milk, cream milk, flavored milk, milk beverage, ice cream mixed processing and cheese.
We have developed a series of processing systems and complete production lines to ensure that every stage of milk processing, from milk receiving and clarification, heat based pasteurization and homogenization to final product processing and storage, meets the most stringent safety requirements without losing valuable nutrients in milk.



High Efficiency Dairy Processing Machines , Milk Production Line 2

Usage:
Applicable for large milk collection center, or for milk outdoor storage at large milk production plant; also used at other food and pharmacy factory for storage of liquid product.This equipment is equipped with cleaning system, agitator, sight and view devices, also have attachments of thermometer and level indication meter.



High Efficiency Dairy Processing Machines , Milk Production Line 3

Usage:
This machine stands between the pasteurizer and the UHT, can be used for PET hot filling or roof shape filling sterilize.
Full automatic control: UK Spirax Sarco steam pressure reduce valve, German Burkert or Spirax Sarco temperature control system, German Labom temperature transducer, Anthone temperature recorder without paper, South hot water pump, Siemens PLC full automatic control with touch screen, the precision of temperature control is ±0.5 degree.
Semiautomatic control: UK Spirax Sarco steam pressure reduce valve, German Burkert or Spirax Sarco temperature control system, German Labom temperature transducer, Anthone temperature recorder without paper, South hot water pump, Siemens LOGO control, the precision of temperature control is ±0.5 degree.

High Efficiency Dairy Processing Machines , Milk Production Line 4









End product package of this Milk processing line can be plastic pouches, plastic cups, plastic bottles, glass bottles, roof top box etc. for this Milk processing line according to different end product and package type, the production technology is differently designed, but commonly include the following steps:



Equipment list of 25T/D DAIRY PRODUCTION LINE
(pasteurized milkyogurtcheesecreambutter)
NO. NAME MAIN TECHNOLOGY PARAMETER
1 MILK RECEIVESTORAGEAND CREAM SEPARETOR UNIT
2 electron pound scale maximum weighing 500KG
3 milk weighing tank made of SUS stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball
4 milk acceptor SUS304 stainless steel,single layer,CIP cleaning ball
5 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
6 twin piping filter SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh
7 dish separator auto residue discharge
8 chiling tank SUS304 stainless steel,alveolate jacket,attached with compressor
9 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
10 PREPARING UNIT
11 blending tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
12 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
13 mini set of plate-type heat exchanger SUS304 stainless steel,two stages,
14 high speed emulsification tank SUS304 stainless steel,heat insulated,bottom high speed emulsifier,digital readout thermometer,supporters with adjustable feet
15 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
16 twin piping filter SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh
17 sterilizing,homogenizing unit
18 UHT sterilizer tub-type,sterilzing temperature 137 C,holding time 4S,full automatic control
19 high pressure homogenizer 40MPa,(starting box included)
20 temperature holding SUS304,holding 300S
21 distributing plate SUS304,3 holes
22 cheesebutter processing unit
23 bufferying tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
24 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
25 cream seperator
26 bufferying container SUS304,with cover
27 milk pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
28 butter-churner SUS304,stepless timing
29 cheese vat SUS304,with heating jacket and insising device
30 pressor SUS304,6 heads
31 mould SUS304,10L,with cover
32 yogurt fermentation unit
33 fermentation tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
34 rotary pump SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift
35 plate cooler SUS304,single stage,milk discharge at 4C
36 rotary pump SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift
37 filling unit
38 higher position tank SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet
39 pasteurized milk filling machine
40 yogurt filling machine
41 CIP system
42 semi-auto CIP system outer coat of SUS304 stainless steel material,inner shell of SUS316,single cleaning way,Concentrated acid/alcali tank adding system based on US technology, 100L×2 acid/alcali Concentrate tanks
43 CIP return pump SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished
44 installation part whole milk processing line installation and commissioning





High Efficiency Dairy Processing Machines , Milk Production Line 5

High Efficiency Dairy Processing Machines , Milk Production Line 6



Pasteurized milk fat
Standardization and cream processing
As a very popular manufacturer of dairy processing equipment, it provides solutions for the production of milk fat products including butter and butter. The design of our equipment and factory is supported by professional technology in all stages of milk fat processing, from raw milk receiving to buffer tank, pasteurization, homogenization, ripening tank, butter mixing, butter melting, heating, cooling, storage and filling. Whether the final product is ready to eat, ready to eat, or as a raw material for the food industry, our processing line solutions ensure that it shows the best quality, taste and texture.
