5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks

Place of Origin China
Brand Name Shanghai Beyond
Certification SGS/CE/ISO9001
Model Number BYDG-2
Minimum Order Quantity 1set
Price negotiation
Packaging Details standard package
Delivery Time 35-60 working days upon receipt of payment and confirmed the drawings
Supply Ability 50 pcs per month
Product Details
Product Name Stainless Steel Food Processing Tanks Warranty 12 Months/1 Year
Material SUS304/SUS316L Function Milk Storage And Juice Storage
Agitator Customized Jacket Type Miller Type
Electric Power Supply 380V 50Hz/110V 60hz/415V 50Hz Sea Port Shanghai Port
Attachment Adjustable Legs
High Light

Food Stainless Steel Mixing Tanks

,

5000L Industrial Storage Tank

,

Automatic Food Processing Tanks SS304

Leave a Message
Product Description

Stainless steel tank manufacturer automatic industrial stainless steel food processing tanks



Provide you with the best series of cans, stainless steel cans, CIP cans, beverage cans, CIP system (local cleaning) and syrup preparation cans, and deliver them effectively and timely.



Minimum order quantity: 1 piece

Storage capacity: 100L, 5000L, 10000l, 15000l, 20000l 50000l

Brand: Beyond

Material: SS316, SS304

Conditions: New

Capacity (liters): customized

Configuration: vertical, horizontal

Design: customization



5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 0

5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 1



Single layer tank ( with agitator or without agitator)

Usage: mainly applicable for storaging and mixing of all kinds of liquid products like: dairy products, juice, beer and brew, chemistry liquid , and biology engineering products, etc;

Specifications:

★Material: All material used is high quality sus304-2B stainless steel or SUS316, shell thickness δ=3-4mm

★Structure feature: normal construction (single layer), cylindrical shape, triangle or cylinder legs.

★Agitator types: with or without agitator; with agitator: wing agitator, anchor type, propeller type; frame type etc.;

Standard configuration

      a). One air tight side manhole;

b). Anti butterfly and dirt air vent;

c). One PT100 thermometer, temperature range 0~100℃;

d). CIP cleaning ball;

                   e). Product inlet/outlet;

                   f). Discharge valve

      g). Adjustable legs;

      h). Sample valve

Technical parameter

Model Volume (L) External diameter(mm)

Height

(mm)

Plate thickness(mm) Diameter of inlet/outlet
BYDG-500 500 800 2140 δ3 φ38
BYDG-1 1000 1050 2380 δ3 φ38
BYDG-1.5 1500 1180 2550 δ3 φ38
BYDG-2 2000 1340 2760 δ3 φ38
BYDG-2.5 2500 1420 2940 δ3 φ38
BYDG-3 3000 1540 3050 δ3 φ38
BYDG-4 4000 1650 3200 δ3 φ38
BYDG-5 5000 1780 3250 δ3 φ38
BYDG-6 6000 1900 3350 δ3 φ38
BYDG-8 8000 2100 3800 δ4 φ65
BYDG-10 10000 2300 4050 δ4 φ65
BYDG-12 12000 2520 4450 δ4 φ65
BYDG-15 15000 2540 4700 δ4 φ65






We are one of the major manufacturers, suppliers, traders and exporters of various types of storage tanks. These tanks are developed and designed using advanced raw materials in accordance with industry specified specifications and guidelines. Stainless steel cans and containers are mainly used in the food industry and the pharmaceutical and chemical industry. We can design and manufacture stainless steel cans and containers according to customers' needs. Our after-sales engineers will guide customers in installation and commissioning, so as to ensure that customers can put new equipment into use in the shortest time. All tanks we provide are widely praised by our valuable customers for their excellent characteristics such as high durability and high tensile strength.



5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 2



5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 3

5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 4



Service flow chart



5000L Automatic Stainless Steel Tanks Industrial Food Processing Tanks 5
