Stainless Steel Wine Fermentation Tank Storage Beer Containing Equipment
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Fermentation Tank | Material | Stainless Steel |
|---|---|---|---|
| Voltage | According To Customer Local Voltage | Power Consumpiton | Energy Saving Type |
| Warranty | 12 Months | Sea Port | Shanghai Port |
| PU Insulation | 50mm | Jacket | 1.5mm |
| Condition | New | Weight | Various In Different Models |
| High Light | Beer Wine Fermentation Tank,Stainless Steel Wine Fermentation Tank,Wine Storage Tank 50mm |
||
Product Description
Stainless Steel Tank Beer And Wine Containing Equipment Wine Fermentation Tank Wine Storage Tank
Beer fermentation tanks are also called (cylindrical conical tanks), (fermentation containers), primary fermentation tanks or unit tanks because they are used for both fermentation and storage. Fermentation is a process in which yeast converts malt juice into beer. Beer will be aged after fermentation, which is the time for beer to stabilize and age after fermentation.
The tank volume can be 100 to 50000L. According to the requirements, the tank material can be stainless steel 304 or stainless steel 316L. The tank diameter and height can be customized according to customer requirements.
Stainless steel tank is a convenient and efficient product storage and transportation equipment.
The stainless steel tank cover can be a foldable open cover or a sealed manhole cover.
| Model | Diameter | External diameter | Height ( mm ) | PU Insulation ( δ ) | Jacket ( δ ) | Diameter of inlet/outlet |
| BYDG-500 | φ500 | 800 | 2140 | 50 | 1.5 | φ38 |
| BYDG-1 | φ1000 | 1050 | 2380 | 50 | 1.5 | φ38 |
| BYDG-1.5 | φ1500 | 1180 | 2550 | 50 | 1.5 | φ38 |
| BYDG-2 | φ2000 | 1340 | 2760 | 50 | 1.5 | φ38 |
| BYDG-2.5 | φ2500 | 1420 | 2940 | 50 | 1.5 | φ38 |
| BYDG-3 | φ3000 | 1540 | 3050 | 50 | 1.5 | φ38 |
| BYDG-4 | φ4000 | 1650 | 3200 | 50 | 1.5 | φ38 |
| BYDG-5 | φ5000 | 1780 | 3250 | 50 | 1.5 | φ38 |
| BYDG-6 | φ6000 | 1900 | 3350 | 50 | 1.5 | φ38 |
| BYDG-8 | φ8000 | 2100 | 3800 | 60 | 1.5 | φ65 |
| BYDG-10 | φ10000 | 2300 | 4050 | 60 | 1.5 | φ65 |
| BYDG-12 | φ12000 | 2520 | 4450 | 60 | 1.5 | φ65 |
The stainless steel fermentation tank can be independently controlled by ethylene glycol jacket, and is mainly equipped with overpressure and underpressure valves, CIP cleaning nozzles, sanitary sampling valves, manholes and other accessories. The design of fermentation tank is based on our rich beer knowledge, especially the bottom of conical fermentation tank. It is very important for us to ferment and ripen in the same container. When calculating fermentation and storage capacity and configuration, sufficient fermentation and storage time must be considered to produce high-quality beer.
Characteristics of fermentation tank
1) Automatic/semi-automatic operating system, which requires one or two brewers to operate.
2) With our equipment, you can brew different kinds of beer, such as beer, beer
Black beer, etc., we provide brewing formula.
3) Our brewery equipment has passed CE, ISO and TUV certification.
4) Get good feedback from our customers.
5) Installation/operation/service/maintenance manual: provided in English.
Fermentation tank configuration:
Design pressure 45 psi; Working pressure 15psi
4 stainless steel legs with horizontal foot pads
Inner shell: 304 stainless steel, 3mm thick
Shell: 304 stainless steel, 2mm thick
The internal and external surfaces shall be polished to 0.6~0.8, and the surface shall be clean
60 degree cone base, other angles can be specified during design
Standard combination drain extension and tapered beer spout
25% of the top space, unless a different volume is requested
Top manhole or side manhole door
Double zones in the sidewall and conical pit cooling jacket with glycol inlet and outlet
The polyurethane insulation thickness of side and bottom cooling jackets is 80mm
Type of fermentation tank:
Process beer equipment, brewer, brewery, stainless steel tank
Beer brewing equipment, beer brewing equipment, beer brewing machine
Brewing system, saccharification system, syrup tank, brewing kettle
Household brewing equipment, brewing system, beer brewing system and micro beer brewing equipment
Industrial brewing equipment and commercial beer brewing equipment for sale
Conical fermentation tank, beer fermentation tank, fermentation tank, ethylene glycol jack conical fermentation tank
Micro brewery equipment, copper brewery equipment, bar brewery, bar/bar beer equipment
