    Aseptic Stainless Steel Storage Tanks / Floor Type Industrial Fermentation Tank

    Product Details:

    Place of Origin: Shanghai China
    Brand Name: Beyond
    Certification: ISO/CE
    Model Number: 10L-100L ,20L-200L、30L-300L、50L-500L、100L-1000L、150L-1500L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: standard exported package
    Delivery Time: 35-60 working days
    Supply Ability: 100 pcs per month
    Get Best Price Contact Now

    Detail Information

    Name: Stainless Steel Primary Seed Tank Fermentation Tank Biological Tank Material: Stainless Steel
    Voltage: According To Customer Local Voltage Power Consumpiton: Energy Saving Type
    Warranty: 12 Months Sea Port: Shanghai Port
    High Light:

    milk storage tank

    ,

    chocolate melting tank

    Product Description

    Aseptic Stainless Steel Storage Tanks / Floor Type Industrial Fermentation Tank

    stainless steel primary seed tank fermentation tank biological tank

    Nominal volume: 10L-100L ,20L-200L,30L-300L,50L-500L,100L-1000L,150L-1500L

    Liquid loading coefficient: ≥70%

    Tank configuration :

    Stainless steel SUS316/SUS304;

    Jacket temperature control,optimized diversion design;

    Interior surface polishing ,Ra≤0.6μm;exterior surface polishing or matte treatment;

    Wide visual angle long-bar sight glass,PH electrode ,DO electrode,temperature electrode with complete connections;

    The tank cover is equipped with the flame inoculation port and standby feeding port.

    Stirring system

    Top mechanical stirring system , aseptic mechanical seal system , DC stirring motor or AC motor;

    Standard configuration 2-layer flat vane , first-class high-efficiency defoaming vane , bending vane and axial flow vane are optional;

    Vailable frequency speed control, digital setting of rotation speed control.

    Structure mode

    Floor type semi-open structure with compact structure , space saving , reasonable layout and easy operation.

    Ventilating system

    Deep ventilating ,full stainless steel pipe;

    Glass rotor flowmeter display , pressure gauge display , manual valve flow adjustment;

    Equipped with German Sartorius high-efficiency bacteria removing filter of stainless shell with a precision of 0.01μm;

    External compressed air is required , equipped with high quality water removing pressure stabilizer for continuous and stable air supply;

    The mass flow controller is optional to automatically control air flow.

    PH control

    Online inspection , 2-way peristaltic pump automatic incremental feeding of acid or alkali solution for adjustment;

    Imported PH electrode realizes high temperature steam disinfection.

    Dissolved oxygen(DO)

    Online inspection , with a range of 0-100% or 0-200%;

    Imported DO electrode realizes high temperature steam disinfection;

    Optional , linked control with rotation speed and ventilation.

    Feeding control

    Standard configuration 1-way peristaltic pump time proportional incremental feeding , with the volume of incremental feeding being displayed and recorded.

    Defoaming mode

    Conducting type foam electrode , automatic alarming in case of abnormal foam situation;

    Standard configuration 1-way peristaltic pump autonmatic/manual incremental feeding of defoaming agent , with the volume of incremental feeding being displayed and recorded.

    Control system

    Application industrial level control system . Siemens PLC controller true color touch screen with complete functions and stable running .

    Sterilizing mode

    SIP , manual control

    Equipment features

    SIP , safe and reliable;

    Wide visual angle vertical sight glass with clear observation;

    Various reliable inoculation modes (standard configuration flame inoculation port,differential pressure inoculation port and other various optional forma);

    Floor type tank with beautiful appearance;

    On the basis of ensuring functions , the pipe system is simplified , making use and maintenance convenient;

    Products of special specifications can be made to order;

    Inoculation pipe SIP without dead corner . Inoculation at the next stage can be carried out .

    Optional

    1.Multi-way feeding

    2.Automatic sterilization

    3.Weighing of fed materials

    4.Tank body weighing

    5.Rich oxygen bypass

    6.ORP online inspection

    7.Air flow automatic inspection and control

    8.Tail gas O2,CO2 content online inspection

    9.Methanol (alcohol) content online inspection

    10.Tank cover automatic hoisting device.



    Aseptic Stainless Steel Storage Tanks / Floor Type Industrial Fermentation Tank 0Aseptic Stainless Steel Storage Tanks / Floor Type Industrial Fermentation Tank 1Aseptic Stainless Steel Storage Tanks / Floor Type Industrial Fermentation Tank 2
